Product: PID-2303-3C
SKU: PID-2303-3C
Categories: Meters, Relays, Timers, Counters, APFC
| INPUT SPECIFICATION: | ||
| Input Types | Input | Range |
| J | 0 to 400°C | |
| K | 0 to 500°C | |
| 3 CT | 0.0 to 60.0 A | |
| Resolution | J,K = 1°C | |
| Indication Accuracy | ±1% of FSD | |
| (FSD:- full scale deflection) | ||
| DISPLAY AND KEYS: | ||
| Display | Upper: 3-Digit, 7-Seg 0.70” White LED | |
| Middle: 3-Digit, 7-Seg, 0.39” Green LED | ||
| Lower: 3-Digit, 7-Seg, 0.33” Red LED | ||
| Keys | SET, INC, DEC, ENT | |
| DIMENSION: | ||
| Size (mm) | 72 (H) x 72 (W) x 85 (D) | |
| Panel Cutout (mm) | 68 (H) x 68 (W) | |
| CONTROL METHOD: | ||
| Heating | 1. PID Control with Auto-Tuning | |
| 2. ON-OFF Control | ||
| Cooling | 1. BL.TP ( Blower Time Proportion) | |
| 2. ON-OFF Control | ||
| Alarm | Heater Break Alarm, Cold Start, High, Low, Absolute Low, Inband, Absolute Outband, OFF, Outband | |
| OUTPUT SPECIFICATION: | ||
| Relay Output | ||
| Relays | 3 Nos | |
| Relay Type | 1st Relay 1C/O (NO-C-NC) , 2nd & 3rd Relay (NO-C) | |
| Rating | 5A,230V AC/28V DC | |
| SSR Drive Output | ||
| Output Signal | 24V DC, 30mA DC | |
| (On-Off condition) | ||
| Relay 1 parallel to SSR | ||
| MODBUS | ||
| RS-485 Modbus Communication | ||
| POWER SUPPLY: | ||
| Supply Voltage | 100 to 270V AC, 50-60Hz | |
| Power Consumption (VA Rating) | Approx 6VA @ 230V AC | |
| ENVIRONMENT CONDITION: | ||
| Operating Temp. | 0°C to 55°C | |
| Relative Humidity | Upto 95% RH | |
| (non-condensing) | ||
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 | |
Sr.no | Model No | Input | Output | RS-485 Modbus | Aux Supply | Size |
| 1 | PID-2303-1C-A2-60AN-X0 | J/K+60A 1CT | Relay || SSR + 2 Relay | 100-270V AC | 72x72x85(HxWxD)mm | |
| 2 | PID-2303-3C-A2-60AX-X0 | J/K+60A 3CT | Relay || SSR + 2 Relay | 100-270V AC | 72x72x85(HxWxD)mm | |
| 3 | PID-2303-1C-M1-A2-60AN-X0 | J/K+60A 1CT | Relay || SSR + 2 Relay | yes | 100-270V AC | 72x72x85(HxWxD)mm |
| 4 | PID-2303-3C-M1-A2-60AN-X0 | J/K+60A 3CT | Relay || SSR + 2 Relay | yes | 100-270V AC | 72x72x85(HxWxD)mm |
| 5 | PID-2302-1C-A2-60AN-X0 | J/K+60A 1CT | Relay || SSR + 1 Relay | 100-270V AC | 72x72x85(HxWxD)mm |
