| Particulars | 7.2 KV | 12 KV | 24 KV | 36 KV |
| Applicable Standards | IEC 60502-4, CENELEC HD 629.1, IS 13573-2 |
| Rated Voltage of cable accessories | 3.8/6.6 (7.2) | 6.35/11 (12) | 12.7/22 (24) | 19/33 (36) |
| Brand | Raychem-RPG | Raychem-RPG | Raychem-RPG | Raychem- RPG |
| Accessories | Heat Shrink type |
| AC Voltage test | 17.1 kV | 28.5 kV | 57.1 kV | 85.5 kV |
| Dry for 5 minutes | 15.2 kV | 25.4 kV | 50.8 kV | 76 kV |
| Wet for 1 minute | | | | |
| DC Voltage test for 15 min | 15.2 kV | 25.4 kV | 50.8 kV | 76 kV |
| Partial Discharge at 1.73U0 | Less than 10 pC |
| Impulse Voltage at ambient & elevated temp | 60 kVp | 75 kVp | 125 kVp | 170 kVp |
| Load Cycle test | 60 cycles in air & water |
| Each cycle heating duration | 5 hours |
| Temperature | 95 - 100° C |
| Cooling Duration | 3 hours |
| Voltage withstand | 9.5 kV | 15.8 kV | 31.7 kV | 47.5 kV |
| Humidity Test for 300 hrs. | 4.7 kV | 7.93 kV | 15.8 kV | 23.7 kV |
| Salt fog test for 1000 hrs. | 4.7 kV | 7.93 kV | 15.8 kV | 23.7 kV |
| Method of Stress Control | Resistive based |
| (ZnO based available in termination on req.) |
| Tubing’s & Molded parts | Heat Shrinkable type |
| Non-Tracking material | As per ASTM D-2303 |
| Di-electric strength of insulating material | 10 kV/mm minimum |
